NDS 824 Class B ADA Compliant Slotted Galvanized Slotted 5" x 20" Grate
NDS 824 Class B ADA Compliant Slotted Galvanized Slotted 5" x 20" Grate
Additional Information
- Grate Width: 5.18" for Pro Series 5
- Grate Height: 0.75"
- Weight: 0.5 lb
- Grate Material / Color / Finish: Galvanized Steel
- Manufacturer: NDS
- System: Pro Series 5
- Grate Load Class: Class B
- Channel Material: Plastic - (PP, HDPE, PE) - Gray
- Application: Residential, General Purpose Drainage - Interior, General Purpose Drainage - External
Description
Galvanized slotted Class B grate for driveway traffic. Grate is for the NDS® Pro Series 5 trench drain system. Open surface area 19.32 square inches per foot. Class B: Loads 61-175 psi. Recommended for medium-duty pneumatic tire traffic, autos, and light trucks at speeds less than 20 mph.
